This is listing is for the SUPERCORE ONLY! You will need to purchase your hot-side exhaust housing separately.
Horsepower: 525 - 1450
Displacement: 2.0L - 8.0L
FEATURES
- GARRETT® G SERIES COMPRESSOR AERODYNAMICS FOR MAXIMUM HORSEPOWER
- 79mm TURBOCHARGER COMPRESSOR OPTION
- FULLY MACHINED SPEED SENSOR AND PRESSURE PORTS
- NEW TURBINE WHEEL AERO FOR INCREASED EFFICIENCY AND FLOW
- STAINLESS STEEL TURBINE HOUSINGS
- WATER FITTINGS INCLUDED
Turbocharger Part Number Chart:
| G42-1450 Supercore Reference Data
SuperCore PN: 860778-5006S |
Compressor | Turbine | |||||
|---|---|---|---|---|---|---|---|
| Inducer | Exducer | Trim | A/R | Inducer | Exducer | Trim | |
| 79mm | 98mm | 65 | 0.85 | 82mm | 75mm | 84 | |
| G42-1450 Turbine Housing Kits | Turbine Kit PN | A/R | Inlet | Outlet | Wastegate | Divided | |
|---|---|---|---|---|---|---|---|
| Free float / non-wastegated turbine housing kits are sold
independently of the supercore |
757707-0011 | 1.01 | V-Band | V-Band | Free Float | N | |
| 757707-0012 | 1.15 | V-Band | V-band | Free Float | N | ||
| 757707-0013 | 1.28 | V-Band | V-band | Free Float | N | ||
| 757707-0014 | 1.01 | T4 | V-band | Free Float | Y | ||
| 757707-0015 | 1.15 | T4 | V-band | Free Float | Y | ||
| 757707-0016 | 1.28 | T4 | V-band | Free Float | Y | ||
